DescriptionThe HPR153i 3-way loudspeaker is a great choice when the warmth, clarity and projection of a horn loaded, cone midrange system is desired. The 15" driver and larger enclosure volume provide extension down to 36 Hz making the HPR153i well suited for reinforcement of music with lots of low frequency content. Mids are handled by a 6" cone driver that seamlessly covers the critical vocal region. A 1.4" (diaphragm) compression driver delivers brilliant top end response. The 600 watt (400 LF/100 MF/100 HF) power module includes a 100 Hz high-pass filter for use in subwoofer-equipped systems.In DepthTransducers- Low Frequency: 15" cone transducer with 3" voice coil - Midrange Frequency: 6.5" horn loaded mid-range - High Frequency: 1.4" diaphragm compression driver - Frequency Response (-3 dB): 41 Hz - 17.5 kHz - Frequency Range (-10 dB): 36 Hz - 20 kHz - Nominal Coverage, -6 dB: 90 degree x 60 degree - Maximum SPL (1 meter): 134 dB peak Amplifier - Power output: 400W LF Class H, 100W HF Class AB+B, 100W HF Class AB+B - Input impedance: 22k balanced, 11k unbalanced - Controls: Gain, Low-cut filter, Front LED On/Off, Power, Circuit breaker - Indicators: Power. Signal, Limit - Cooling: Convection - Amplifier protection: Thermal and Output Limiting, Output Short Circuit, Overtemperature Muting, Driver DC Protection - Current consumption at 120 VAC (1/8 power EIA noise): 1.8A - Enclosure: Painted Birch plywood - Finish: Black textured paint - Grille: Powder coated 16 gauge steel - Connectors: Balanced female XLR line level input, Balanced male XLR full range line level out - Suspension / Attachment Points: 3 M10 rigging locations - Dimensions: 44.75" H x 19" W x 18" D (1137mm x 485mm x 455mm) - Net weight: 118 lbs. / 54 kg
Item Number:
QSC HPR153i [HPR153i]
