Transparent, airy uppers and mids, coupled with a rich, silky smooth low end, make the e3002 CAD’s finest vocal mic. combining lightning fast transient response and pinpoint precision with an enormous upfront presence, the e3002 offers uparalleled performance from critical studio tracking scenarios to live reinforcements.
1.1" 24K gold sputtered externally biased triple pattern dual diaphragm condenser capsule, hand dampened for consistent frequency response
Hi-pass filter 6dB / octave @ 80Hz, and 20dB non-capacitive pad
Stainless/brass triple stage pop/EMI filter for unmatched ballistic stability, high SPL characteristics and plosives control
Sophisticated laser trimmed op-amp circuitry for increased management of fast transient response
Type: Side-address, externally biased condenser
Frequency response: 10 Hz - 20 kHz
Polar Pattern: Cardioid, Omni, Figure 8
Impedence: Low (200 ohms nominal)
Open Circuit Voltage: -55dB (0dB = 1 volt per microbar)
Dynamic Range: 137dB
Equivalent Noise Level: 11dB equivalent SPL, A weighted
Maximum SPL: 148dB SPL (with pad on)
Total Harmonic Distortion: Less than 0.15%
Powering: 24 - 52 Volts Phantom Power, 8mA
Connector: Gold plated 3-pin XLR type
Finish: Durable Black uerethane housing with brass plated front grille screen
Net Weight: 18oz. (510 grams)
